- From 150kg up to 300kg
- Weight up to 300 KG
- New design
- Quick installation even on existing shutters
- Reversible
- Manual release
- Mechanical limit switch built-in, easy adjustable
- Fast, reliable and silent
- Power supply 230 Vac
Models and Codes
- 1000043 | ROLL 200: Roller shutter operator 150 kg – Ø 48-60 – Reversibile
- 1000099/5 | ROLL 240: Roller shutter operator 170 kg with electrobrake 170 kg – Ø 76-101
- 1000099/6 | ROLL 200 – 2M: Double roller shutter operator 300 kg with electrobrake – Ø 48-60
- 1000099/7 | ROLL 240 – 2M: Double roller shutter operator 300 kg with electrobrake – Ø 76 – 101
Performance requirements
| A |
B |
C |
|
| ROLL 200 150KG |
60/48 MM | 200/220 MM | 320 MM |
| ROLL 200/2M 300KG | 60/48 MM | 200/220 MM | 320 MM |
| ROLL 240 170KG | 76 MM | 240 MM | 320 MM |
| ROLL 240/2M 300KG | 76 MM | 240 MM | 320 MM |
Technical features
| ROLL 200 |
ROLL 240 |
ROLL 200-2M |
ROLL 240-2M |
|
| POWER SUPPLY |
230 VAC | 230 VAC | 230 VAC | 230 VAC |
| LIFTING FORCE | 150 KG | 170 KG | 300 KG | 300 KG |
| CONDENSER | 16 UF | 20 UF | 35 UF | 40 UF |
| AVERAGE ABSORPTION | 2A | 2,8A | 2×2,8A | 2×2,8A |
| ABSORBED POWER | 400 W | 600 W | 2×600 W | 2×600 W |
| RPM RING | 9/MIN | 8/MIN | 8/MIN | 8/MIN |
| OPERATOR WEIGHT | 8 KG | 9 KG | 11 KG | 13 KG |
| ENVIRONMENTAL CONDITIONS | -20/+85° C | -20/+85° C | -20/+85° C | -20/+85° C |
| LIMIT SWITCH | 7/8 MT | 7/8 MT | 7/8 MT | 7/8 MT |
