- Arms up to 3 mt
- Irreversible, intensive use
- Powder coated steel structure
- Engine housing in cast aluminum
- Steel and bronze gears
- High performance electric motor
- Air cooling by fun
- Oil lubrication of mechanical parts
- Microswitches in opening and closure
- Balance with spring
- Optional round arm standard – rectangular arm optional
- Emergency release by knob
- Max lenght arm 6 mt. – kit led optional
- Easy programming software
- Control unit with receiver and built-in aerial
- Anti squashing system (en 12453)
- Mechanical slowing down function in openin and closing
- Electronic torque control
Models and Codes
- 1447 | ITALO 230V: Barrier – Contro unit with riceiver 433 mHz
Performance requirements
- Operating cycle intensivo
- Frequency of use 100%
- Opening 3 sec.
Technical features
| POWER SUPPLY | 230 Vac |
| MAX LENGHT ARM |
3 MT |
| OPENING TIME |
3 SEC |
| ABSORBED POWER | 250 W |
| OPERATOR WEIGHT | 45 KG |
| NOISE LEVEL | < 30 DBA |
| ENVIRONMENTAL CONDITIONS | -20/+55° C |
| DEGREE OF PROTECTION | IP44 |
