- Max surface 10mq with 1 motor
- Irrevesible electromechanical operator
- Steel and bronze gears obtained from soild
- Very quiet operation
- Mechanical parts lubricated with lithium grease against oxidation corrosion and rust
- High performance electric motor
- Operator 24Vdc with encoder standard / operator 230Vac with encoder optional
- Start button placed on the cover
- Release device with die-cast lever available with and without control unit
- Control unit with built in radio receiver and aerial
- Pre-wired and easy programming software
- Electronic torque control
- Anti-squashing system (en 12453)
- Slowing down function (en 12453)
- Courtesy light
- Power supply 230Vac – 24Vdc with encoder
Models and Codes
- 759/09 | BASIC 09 230: Operator – Without control unit
- 110411/09 | BASIC 09 230: Operator – Control unit and receiver 433 mHz
- 100034/09E | BASIC 09 24: Operator – Control unit and receiver 433 mHz – Encoder
Performance requirements
- Operating cycle semi-intensivo 230Vac, intensivo 24Vcc
- Frequency of use 50% (230Vac) – 80% (24Vcc)
- Opening 15 sec.
Technical features
| BASIC 09 230 Vac |
BASIC 09 24 Vcc ENCODER |
|
| POWER SUPPLY | 230 Vac | 24 Vcc |
| MAX SURFACE |
10 MQ | 10 MQ |
| ENGINE RPM | 1400 RPM | 1800 RPM |
| AVERAGE ABSORPTION | 1 A | 3 A |
| ABSORBED POWER | 250 W | 50 W |
| CONDENSER | 12,5 UF | – |
| OPERATOR WEIGHT | 8,5 KG | 8,5 KG |
| NOISE LEVEL | < 30 DBA | < 30 DBA |
| ENVIRONMENTAL CONDITIONS |
-20/55°C | -20/55°C |
| DEGREE OF PROTECTION | IP30 | IP30 |
| MAX TORQUE | 200 NM | 200 NM |
