- Leaf weight 2500 Kg
- Structure in die-cast aluminum, powder painted
- Steel and cast gears obtained from solid
- Stator and mechanical parts in oil bath
- Available with and without control unit
- Control unit with built in radio receiver and aerial, control unit box with air-stop seal against moisture and insects
- Pre-wired and easy programming software
- High-performance electric motor
- Mechanical limit switch
- Release device with customized key
- Electronictorque control
- Very quiet operation
- Anti-squashing system and slowing down function (en 12453)
- Power supply 230Vac – 380Vac
Available in fast version ![](https://www.vdsautomation.com/wp-content/uploads/2017/07/Prove-logo-express-0-300x70.png)
Models and Codes
- A3500 | AT PLUS 230V: Operator – Leaf weight up to 2500 kg – Fixing plate – Without control unit
- A3500/1 | AT PLUS TRIFASE 380V: Operator – Leaf weight up to 2500 kg – Triphase 380V – Fixing plate – Without control unit
- 10035/1 | AT PLUS 230V CQ: Operator – Leaf weight up to 2500 kg – Fixing plate – Control unit and receiver 433 mHz
Performance requirements
- Operating cycle: semi-intensive 230Vac, intensive 24Vcc
- Frequency of use: 50% (230Vac) – 80% (24Vcc)
- Speed: 10 mt./min. (230 Vac) – 12 mt./min. (24 Vcc)
Technical features
AT PLUS 2500 |
AT PLUS 2500 Three-phase |
|
POWER SUPPLY | 230 Vac | 380 Vac |
LEAF WEIGHT | 2500 KG | 2500 KG |
PINION | M4-Z16 | M4-Z16 |
ENGINE RPM | 1400 RPM | 1400 RPM |
AVERAGE ABSORPTION | 2,4 A | 2,4 A |
ABSORBED POWER | 650 W | 650 W |
CONDENSER | 25 UF | – |
OPERATOR WEIGHT | 18 KG | 18 KG |
NOISE LEVEL | < 30 DBA | < 30 DBA |
ENVIRONMENTAL CONDITIONS | -20/+55° C | -20/+55° C |
DEGREE OF PROTECTION | IP44 | IP44 |
